Overview

Tackle High Volumes with Speedbox

The Speedbox channel filling system is ideally suited to fast-moving inventory and can easily handle high demand volumes. Channel sizes can be configured according to the medication pack size.

  • Fastest dispensing system
  • Handles high demand volumes
  • 1 Speedbox—Up to 2,400 packs/hour
  • 2 Speedboxes—Up to 3,300 packs/hour
  • 3 Speedboxes—Up to 4,200 packs/hour

  • Multiple units can be installed side by side to increase speed and capacity

Benefits

Details

Specifications

Dimensions:

Height: Made to measure, from 1.65 m to 3.50 m in 0.05‑m increments

Width: Model N = 1.5 m XL = 2.3 m XXL = 3.1 m

Depth: 0.87 m

Structural shapes:

  • Speedbox N with one magazine
  • SPEEDBOX XL with two magazines
  • SPEEDBOX XXL with three magazines

Power supply: 230 V AC/50 Hz

Power consumption: 0.1 to 0.4 kW

Packs that can be stored:

  • Cubic: min. (L/W/H) 135 x 26.5 x 14 mm
  • Cubic: max. (L/W/H) 160/220* x 111 x 57 mm
  • Other forms possible with the aid of outer packaging or auxiliary loading carriers

Pack weight: Max. 1,000 g

Storage capacity: Up to 9,000 packs

Removal from storage: Up to 720/2,400* packs/hour

*A multi-picking handling system for the Speedbox is optionally available.
